50Ω SMPM Male RF Connector 0.3MHz-40GHz 170V for PCB

Brand Name : ELT

Model Number : SSMP-JHD19

Certification : ISO9001, IS014001

Place of Origin : Xi'an, China

MOQ : MOQ 100 pieces

Price : The price depend on the quantity

Payment Terms : T/T,L/C,D/P

Supply Ability : As requirements

Delivery Time : 8-12 weeks for new production

Packaging Details : 100pcs/bag or plastic bottle;100pcs/carton as requirement

Product Name : SMPM Male PCB Connectors

Model : SSMP-JHD19

Frequency Range : 0.3MHz-40GHz

Impedance : 50Ω

Rated Voltage : 170v

DWV : 500V

Insulation Resistance : ≥5000MΩ

Center Conductor : Kaval Alloy, Gold Plated

Outer Conductor : Kaval Alloy, Gold Plated

Samples : Available，In Stock

Contact Now

50Ω SMPM Male Full Detent 4 Leg RF Coaxial Connector 0.3MHz-40GHz 170V for PCB Soldering

Product Description

The SMPM coaxial connector features a compact design optimized for small package requirements, making it ideal for high data rate applications. Its superior shielding capabilities minimize signal interference, ensuring optimal signal transmission at high speeds.

When paired with an SMPM female-to-female adapter, this connector system provides reliable board-to-board connections while compensating for radial and axial misalignments during installation. This makes the SMPM coaxial connector an excellent choice for high-performance applications requiring precision in compact spaces.

Product Specifications

Item	Value
Product Name	SMPM Male PCB Connector
Model	SSMP-JHD80
Frequency Range	0.3MHz-40GHz
Impedance	50Ω
Rated Voltage	170V
DWV	500V
Insulation Resistance	≥5000MΩ
Center Conductor	Kaval Alloy, Gold Plated
Outer Conductor	Kaval Alloy, Gold Plated
Insulation Dielectric	Glass

Product Outline Dimensions (Unit: mm)

50Ω SMPM Male RF Connector 0.3MHz-40GHz 170V for PCB

Note 1:Hermetic Note 2:Engagement Depth 1.4 Note 3: Engagement Depth 1.7 Note 4:Engagement Depth 1.95 Note 5: Engagement Depth 2.11

Applications

Microwave communication systems
Measurement equipment
Aerospace applications
Radar systems
Electronics fields

Elite Electronic manufactures SMPM connectors using premium materials and rigorous quality control processes to ensure exceptional durability and reliability in extreme environments.

Packaging & Shipping

Each SMPM connector is carefully packaged in protective cartons to ensure safe transit. We use reliable courier services with tracking numbers provided for all shipments.

For model availability and additional series options, please contact us at sales3@xa-elite.com.cn.
Note: While some models are in stock, all catalog-listed models can be produced quickly upon request.
